Building information modeling (BIM) is a process involving the generation and management of digital representations of physical and functional characteristics of places. BIM is supported by various tools, technologies and contracts. Building information models (BIMs) are computer files (often but not always in proprietary formats and containing proprietary data) which can be extracted, exchanged or networked to support decision-making regarding a built asset. BIM software is used by individuals, businesses and government agencies who plan, design, construct, operate and maintain buildings and diverse physical infrastructures, such as water, refuse, electricity, gas, communication utilities, roads, railways, bridges, ports and tunnels.
Some purposes or uses of BIM may be described as ‘dimensions’. However, there is little consensus on definitions beyond 5D. Some organisations dismiss the term; for example, the UK Institution of Structural Engineers does not recommend using nD modelling terms beyond 4D, adding “cost (5D) is not really a ‘dimension’.
3D
3D BIM, an acronym for three-dimensional building information modeling, refers to the graphical representation of an asset’s geometric design, augmented by information describing attributes of individual components. 3D BIM work may be undertaken by professional disciplines such as architectural, structural, and MEP, and the use of 3D models enhances coordination and collaboration between disciplines. A 3D virtual model can also be created by creating a point cloud of the building or facility using laser scanning technology.
4D
4D BIM, an acronym for 4-dimensional building information modeling, refers to the intelligent linking of individual 3D CAD components or assemblies with time- or scheduling-related information. The term 4D refers to the fourth dimension: time, i.e. 3D plus time.
4D modelling enables project participants (architects, designers, contractors, clients) to plan, sequence the physical activities, visualise the critical path of a series of events, mitigate the risks, report and monitor progress of activities through the lifetime of the project. 4D BIM enables a sequence of events to be depicted visually on a time line that has been populated by a 3D model, augmenting traditional Gantt charts and critical path (CPM) schedules often used in project management. Construction sequences can be reviewed as a series of problems using 4D BIM, enabling users to explore options, manage solutions and optimize results.
As an advanced construction management technique, it has been used by project delivery teams working on larger projects. 4D BIM has traditionally been used for higher end projects due to the associated costs, but technologies are now emerging that allow the process to be used by laymen or to drive processes such as manufacture.
5D
5D BIM, an acronym for 5-dimensional building information modeling refers to the intelligent linking of individual 3D components or assemblies with time schedule (4D BIM) constraints. and then with cost-related information. 5D models enable participants to visualise construction progress and related costs over time. This BIM-centric project management technique has potential to improve management and delivery of projects of any size or complexity.
In June 2016, McKinsey & Company identified 5D BIM technology as one of five big ideas poised to disrupt construction. It defined 5D BIM as “a five-dimensional representation of the physical and functional characteristics of any project. It considers a project’s time schedule and cost in addition to the standard spatial design parameters in 3-D.
6D
6D BIM, an acronym for 6-dimensional building information modeling, is sometimes used to refer to the intelligent linking of individual 3D components or assemblies with all aspects of project life-cycle management information. However, there is less consensus about the definition of 6D BIM; it is also sometimes used to cover use of BIM for sustainability purposes.
In the project life cycle context, a 6D model is usually delivered to the owner when a construction project is finished. The “As-Built” BIM model is populated with relevant building component information such as product data and details, maintenance/operation manuals, cut sheet specifications, photos, warranty data, web links to product online sources, manufacturer information and contacts, etc. This database is made accessible to the users/owners through a customized proprietary web-based environment. This is intended to aid facilities managers in the operation and maintenance of the facility.
The term is less commonly used in the UK and has been replaced with reference to the Asset Information Requirements (AIR) and an Asset Information Model (AIM) as specified in BS EN ISO 19650-3:2020
